Swivel Adaptor Clamp

Engineered to international standards for safety, speed and durability on every job site.

Overview

The Swivel Adaptor Clamp is a forged connector that locks a standard scaffold tube onto a ringlock rosette while allowing the tube angle to be set anywhere around the bolt axis. Model TCSWAC weighs 1.6 kgs, is hot dip galvanized and ships FOB Shanghai from ACE SCAFFOLD.

Swivel Adaptor Clamp - Adjustable Forged Rosette Adapter Clamp TCSWAC

Key Features

  • Forged adjustable clamp connects a scaffold tube to a ringlock rosette at variable angles
  • Rosette end engages the ringlock node; tube end swivels around the bolt axis
  • Tube grip closes on a 48.3 mm OD tube and locks at the required angle
  • Hot dip galvanized for corrosion resistance on site and outdoors
  • Made to EN74, BS1139, EN12810 and ASTM standards
  • Forged steel, 1.6 kgs, FOB Shanghai from ACE SCAFFOLD

The Swivel Adaptor Clamp joins a ringlock rosette to a scaffold tube that does not need to sit at a fixed angle. One side of the clamp drops onto the rosette and is locked with a wedge or bolt; the other side carries a hinged or rotating tube grip that closes on a 48.3 mm outside-diameter tube. Because the grip can swivel around the rosette fastener, the tube can leave the scaffold at the angle required by the layout rather than a preset 90 degrees. The forged steel body keeps the joint rigid once the bolt is tightened, and the hot dip galvanized finish protects the clamp on site. It is made to EN74, BS1139, EN12810 and ASTM standards and fits ringlock and compatible rosette scaffolding.

What a Swivel Adaptor Clamp Does

The Swivel Adaptor Clamp fixes a scaffold tube to a ringlock rosette while letting the tube angle be adjusted around the bolt axis. Use it where a tube must leave the scaffold face at an angle that is not 90 degrees, such as a sloping brace, a transition handrail or an offset connection.

How It Connects to the Rosette

The clamp presents a rosette interface on one face and a tube grip on the other. The rosette end drops onto the ringlock rosette and is locked with its wedge or bolt. A swivel joint between the rosette plate and the tube grip lets the grip rotate so the tube can be set to the required angle before the bolt is tightened.

Forged for a Rigid Joint

Built from forged steel, the clamp keeps the tube-to-rosette joint rigid once the swivel bolt is tightened. The hinge or lug that carries the tube grip is sized to take the working loads of a perpendicular or angled tube without deforming.

Hot Dip Galvanized Finish

TCSWAC is supplied hot dip galvanized for corrosion resistance in outdoor and site conditions, protecting the clamp through repeated assembly, disassembly and storage.

Standards and Compatibility

The clamp is produced to EN74, BS1139, EN12810 and ASTM, and fits ringlock and compatible rosette scaffolding with a 48.3 mm tube. ACE SCAFFOLD supplies TCSWAC FOB Shanghai with OEM/ODM available.

Swivel Adaptor Clamp Specifications

DescriptionMODELUnit Weight
Swivel adapter clampTCSWAC1.6 kgs

Frequently Asked Questions

Q
What is a swivel adaptor clamp used for?
It fixes a standard scaffold tube to a ringlock rosette while allowing the tube angle to be adjusted around the bolt axis. Use it for sloping braces, transition handrails or offset connections that do not sit at 90 degrees.
Q
Which tube size does the swivel adaptor clamp fit?
The tube grip closes on a 48.3 mm outside-diameter scaffold tube, the standard tube used on ringlock and compatible rosette scaffolding systems.
Q
What standards does the TCSWAC clamp meet?
TCSWAC is produced to EN74, BS1139, EN12810 and ASTM. It is forged steel, hot dip galvanized, weighs 1.6 kgs and is supplied FOB Shanghai by ACE SCAFFOLD with OEM/ODM available.
Q
How does the swivel action work?
The tube grip is mounted on a swivel joint around the rosette fastener. Loosen the bolt, set the tube to the required angle, then tighten the bolt to lock the joint rigid.
