QES Scaffold Base Collar

Engineered to international standards for safety, speed and durability on every job site.

Overview

The QES Scaffold Base Collar - also called a QES base collar or Quick Erect Scaffold base collar - is the galvanized steel ring fitting that sits at the foot of a QES post and provides the first forged-ring connection point at ground level. It carries the QES forged ring so the bottom bay uses the same captive-wedge horizontals as every other lift, letting the tower start square and level on a base plate or screw jack. As a QES manufacturer, we provide OEM/ODM, ISO 9001 and FOB Shanghai delivery.

QES Scaffold Base Collar - Quick Erect Scaffold Base Component

Key Features

  • Hot-dip galvanized steel for durability and long service life
  • Adds the first forged-ring connection at the foot of the QES post
  • Bottom bay uses the same captive-wedge horizontals as every lift
  • Keeps the first lift square, level and fully connected
  • Model QLC: 2.85 kgs (6.27 lbs)
  • Core base fitting of the fast-erecting QES system

The QES Scaffold Base Collar is the base fitting of the Quick Erect Scaffold system - a hot-dip galvanized steel collar that clamps over the foot of the QES post and carries a forged ring, so ledgers and braces can lock in right above the base instead of leaving a weak, open first lift.

The QES Scaffold Base Collar is the base fitting of the Quick Erect Scaffold (QES) system. It is a hot-dip galvanized steel collar that clamps over the foot of the QES post and carries a forged ring, giving the bottom bay the same captive-wedge connections as the rest of the tower.

A QES bay normally starts with a bare post on a base plate or screw jack. The base collar adds a forged ring at that lowest point, so horizontals and braces lock in right above the base - keeping the first lift square, level and fully connected.

QES Scaffold Base Collar Model

One standard size covers most layouts: the QLC base collar, weighing 2.85 kgs (6.27 lbs) with a hot-dip galvanized finish for durability on site.

The QES Scaffold Base Collar works with our QES Scaffold Post and QES Scaffold system to give the tower a square, level starting point on a base plate or screw jack.

QES Scaffold Base Collar Specifications

DescriptionMODELWeight (kgs)Weight (lbs)Surface
BASE COLLARQLC2.856.27Hot-dip Galvanized
